Specifications
PDF(1)
| TYPE | DESCRIPTION |
| Mfr | 3PEAK |
| Series | - |
| Package | Tape & Reel (TR) |
| Product Status | ACTIVE |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C |
| On-State Resistance (Max) | 80Ohm |
| -3db Bandwidth | 200MHz |
| Supplier Device Package | 16-SOIC |
| Voltage - Supply, Single (V+) | 3V ~ 12V |
| Crosstalk | -70dB @ 1MHz |
| Switch Circuit | SPDT - Open/Closed |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Channel-to-Channel Matching (ΔRon) | 15Ohm |
| Switch Time (Ton, Toff) (Max) | 60ns, 50ns |
| Channel Capacitance (CS(off), CD(off)) | 5pF, 5pF |
| Current - Leakage (IS(off)) (Max) | 400nA |
| Number of Circuits | 3 |
